Description

Another Practice piece, might be useful to someone.

*** I am NOT an Electrician and this should NOT be used as a guide for anything, let alone electrics! ***

Comments (7)

init999 about 5 years ago

I am an electrician (Spanish) and I congratulate you on the design (CAD). Another question is whether it is a correct design from an electrical point of view, although it seems that it is.

baldyman_1248537 about 5 years ago

Thanks. I'm qualified in electronics rather than electrics, so the basic wiring is right. However there are all sorts of regulations regarding fireproofing of cable entry points, the tails are not double insulated etc etc. So, it would work but I doubt it would pass a safety inspection!

paranoidalandroid about 5 years ago

What did you use as reference? multi9 breakers?

baldyman_1248537 about 5 years ago

Loosely based on the Acti 9

StüpendøusWillStudiøs about 5 years ago

Thanks... If you don't mind, I need to use this in an upcoming game, and, although I normally use only my own-made assets, I make a few exceptions, and this is too good to ignore. I see this is CC-BY. Great job. Needed this.

baldyman_1248537 about 5 years ago

Please feel free.

Navindu Jayawardane almost 5 years ago

thank i Am very important
